LT1490ACDD Integrated Circuit Chip Operational Amplifiers DFN8 Linear Amplifiers

LT1490ACDD Integrated Circuit Chip Operational Amplifiers DFN8 Linear Amplifiers​

Product Description Of LT1490ACDD

LT1490ACDD is dual Operational Amplifiers with a low input offset voltage of 500μV max. The LT1490ACDD operate on all single and split supplies with a total voltage of 2V to 44V, drawing only 40μA of quiescent current per amplifier.

Specification Of LT1490ACDD

Features Of LT1490ACDD

Low Input Offset Voltage: 500μV Max
Output Swings to 10mV Max from V–
Rail-to-Rail Input and Output
Micropower: 50μA/Amplifier Max
Over-The-Top® Input Common Mode Range Extends 44V Above V–, Independent of V+
Specified on 3V, 5V and ±15V Supplies
High Output Current: 20mA
Output Drives 10,000pF with Output Compensation
Reverse Battery Protection to 18V
No Supply Sequencing Problems
High Voltage Gain: 1500V/mV
High CMRR: 98dB
No Phase Reversal
Gain Bandwidth Product: 200kHz
Tiny 3mm × 3mm × 0.8mm DFN Package

Applications Of LT1490ACDD

Battery- or Solar-Powered Systems
Portable Instrumentation
Sensor Conditioning
Supply Current Sensing
Battery Monitoring
Micropower Active Filters
4mA to 20mA Transmitters
