MKL16Z32VFM4 Microcontroller MCU 48MHz Cortex-M0+ Ultra-Low Power Mainstream MCU

MKL16Z32VFM4 Microcontroller MCU 48MHz Cortex-M0+ Ultra-Low Power Mainstream MCU

Product Description Of MKL16Z32VFM4
MKL16Z32VFM4 is a general purpose ultra-low-power MCU family, providing additional memory, communications and analog peripheral options beyond those offered in the Kinetis KL0x MCU family.

The KL1x MCU family is compatible with Kinetis K10 MCUs (based on Arm® Cortex®-M4) and with all other Kinetis KL1x, KL2x, KL3x and KL4x series MCUs, providing a migration path to higher performance and feature integration.

Specifications Of MKL16Z32VFM4

Feature Of MKL16Z32VFM4
Next-generation 32-bit Arm® Cortex®-M0+ core: 2x more CoreMark/mA than the closest 8/16-bit architecture
Single-cycle fast I/O access port facilitates bit banging and software protocol emulation, keeping an 8-bit "look and feel"
Multiple flexible low-power modes, including new compute clocking option which reduces dynamic power by placing peripherals in an asynchronous stop mode
LPUART, SPI, I²C, FlexIO, ADC, DAC, LP timer and DMA support low-power mode operation without waking up the core
Up to 256 KB flash with 64 byte flash cache, up to 32 KB RAM
Security circuitry to prevent unauthorized access to RAM and flash contents
16 KB ROM and built-in boot loader simplifies the effort to program MCU and allows for easy flash upgrades
Arm® Cortex®-M0+ core, 48 MHz core frequency over full voltage and temperature range (-40ºC to +105ºC)
Bit manipulation engine for improved bit handling of peripheral modules
Thumb instruction set combines high code density with 32-bit performance
Up to 4-ch. DMA for peripheral and memory servicing with reduced CPU loading and faster system throughput
Independent-clocked COP guards against clock skew or code runaway for fail-safe applications
Up to 16-bit ADC with configurable resolution, sample time and conversion speed/power
Integrated temperature sensor
High-speed comparator with internal 6-bit DAC
12-bit DAC with DMA support

Applications Of MKL16Z32VFM4
Automotive
Heating Ventilation and Air Conditioning (HVAC)
Motorcycle Engine Control Unit (ECU) and Small Engine Control
Smart Car Access
Consumer
Air Conditioning (AC)
Hearables
Major Home Appliances
Robotic Appliance
Small and Medium Appliances
Industrial
Automatic Vehicle Identification
Automotive Gas Meter
Continuous Glucose Monitoring (CGM)
Heat Meter
Motion Control and Robotics
Power Grid Converter
Smart Power Socket
Smart Watch and Wristband
Transport Ticketing
Vital Signs Monitors
Water Meter
