ADP2384ACPZN Integrated Circuit Chip 20V 4A Synchronous Step-Down DC-To-DC Regulator

Large Image : ADP2384ACPZN Integrated Circuit Chip 20V 4A Synchronous Step-Down DC-To-DC Regulator

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	ADP2384ACPZN

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	LFCSP-24
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

ADP2384ACPZN Integrated Circuit Chip 20V 4A Synchronous Step-Down DC-To-DC Regulator

Description

Part Number:	ADP2384ACPZN	Output Current::	4 A
Number Of Outputs::	1 Output	Input Voltage - Min::	4.5 V
Input Voltage - Max::	20 V	Quiescent Current::	2.9 MA
Highlight:	ADP2384ACPZN , ADP2384ACPZN Integrated Circuit Chip , Synchronous Step-Down DC-To-DC Regulator

ADP2384ACPZN Integrated Circuit Chip 20V 4A Synchronous Step-Down DC-To-DC Regulator

Product Description Of ADP2384ACPZN
ADP2384ACPZN is a synchronous, step-down dc-to-dc regulator with an integrated 44 mΩ, high-side power MOSFET and an 11.6 mΩ, synchronous rectifier MOSFET to provide a high efficiency solution in a compact 4 mm × 4 mm LFCSP package. This device uses a peak current mode, constant frequency pulse-width modulation (PWM) control scheme for excellent stability and transient response. The switching frequency of the ADP2384ACPZN can be programmed from 200 kHz to 1.4 MHz. To minimize system noise, the synchronization function allows the switching frequency to be synchronized to an external clock.

Specifications Of ADP2384ACPZN

Output Voltage:	Adjustable
Output Current:	4 A
Number of Outputs:	1 Output
Input Voltage - Min:	4.5 V
Input Voltage - Max:	20 V
Quiescent Current:	2.9 mA
Switching Frequency:	200 kHz to 1.4 MHz
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 125 C
Height:	0.73 mm
Length:	4 mm
Width:	4 mm
Unit Weight:	51.300 mg

Features Of ADP2384ACPZN
Input voltage: 4.5 V to 20 V
Integrated MOSFET: 44 mΩ/11.6 mΩ
Reference voltage: 0.6 V ± 1%
Continuous output current: 4 A
180° out of phase clock synchronization
Synchronizes to external clock: 200 kHz to 1.4 MHz
Programmable switching frequency:200 kHz to 1.4 MHz
Precision enable and power good
External compensation
Internal soft start with external adjustable option
Startup into a precharged output

Applications Of ADP2384ACPZN
Communications infrastructure
Networking and servers
Industrial and instrumentation
Healthcare and medical
Intermediate power rail conversion
DC-to-DC point-of-load applications
