KSZ9031RNXCA Ethernet IC Gigabit Ethernet Transceiver QFN48 Triple Speed Ethernet PHYs

KSZ9031RNXCA Ethernet IC Gigabit Ethernet Transceiver QFN48 Triple Speed Ethernet PHYs

Product Description Of KSZ9031RNXCA

KSZ9031RNXCA is a completely integrated triple-speed (10BASE-T/100BASE-TX/1000BASE-T) Ethernet physicallayer transceiver for transmission and reception of data on standard CAT-5 unshielded twisted pair (UTP) cable.
KSZ9031RNXCA provides the Reduced Gigabit Media Independent Interface (RGMII) for direct connection to RGMII MACs in Gigabit Ethernet processors and switches for data transfer at 10/100/1000 Mbps.

Specification Of KSZ9031RNXCA

Features Of KSZ9031RNXCA

Single-Chip 10/100/1000 Mbps Ethernet Transceiver Suitable for IEEE 802.3 Applications
RGMII Timing Supports On-Chip Delay According to RGMII Version 2.0, with Programming Options for External Delay and Making Adjustments and Corrections to TX and RX Timing Paths
RGMII with 3.3V/2.5V/1.8V Tolerant I/Os
Auto-Negotiation to Automatically Select the Highest Link-Up Speed (10/100/1000Mbps) and Duplex (Half/Full)
On-Chip Termination Resistors for the Differential Pairs
On-Chip LDO Controller to Support Single 3.3V Supply Operation – Requires Only One External FET to Generate 1.2V for the Core
Jumbo Frame Support up to 16 KB
125 MHz Reference Clock Output
Energy Detect Power-Down Mode for Reduced Power Consumption When the Cable is Not Attached
Wake-On-LAN (WOL) Support with Robust Custom-Packet Detection
Programmable LED Outputs for Link, Activity, and Speed
Baseline Wander Correction
LinkMD TDR-Based Cable Diagnostic to Identify Faulty Copper Cabling
Parametric NAND Tree Support to Detect Faults Between Chip I/Os and Board
Loopback Modes for Diagnostics
Automatic MDI/MDI-X Crossover to Detect and Correct Pair Swap at all Speeds of Operation
Automatic Detection and Correction of Pair Swaps, Pair Skew, and Pair Polarity
MDC/MDIO Management Interface for PHY Register Configuration
Interrupt Pin Option
Power-Down and Power-Saving Modes
48-pin QFN (7 mm × 7 mm) Package

Applications Of KSZ9031RNXCA
Laser/Network Printer
Network Attached Storage (NAS)
Network Server
Gigabit LAN on Motherboard (GLOM)
Broadband Gateway
Gigabit SOHO/SMB Router
IPTV
IP Set-Top Box
Game Console
Triple-Play (Data, Voice, Video) Media Center
Industrial Control
Automotive In-Vehicle Networking
