LTC4412IS6 Integrated Circuit Chip OR Controller 11μA Low Loss PowerPath Controller

LTC4412IS6 Integrated Circuit Chip OR Controller 11μA Low Loss PowerPath Controller

Product Description Of LTC4412IS6

LTC4412IS6 is Low Loss PowerPath™ Controller in ThinSOT Package. LTC4412IS6 controls an external P-channel MOSFET to create a near ideal diode function for power switchover or load sharing. This permits highly efficient OR’ing of multiple power sources for extended battery life and low self-heating. When conducting, the voltage drop across the MOSFET is typically 20mV. For applications with a wall adapter or other auxiliary power source, the load is automatically disconnected from the battery when the auxiliary source is connected. Two or more LTC4412IS6 may be interconnected to allow load sharing between multiple batteries or charging of multiple batteries from a single charger.

Specification Of LTC4412IS6

Features Of LTC4412IS6

Very Low Loss Replacement for Power Supply OR’ing Diodes
Minimal External Components
Automatic Switching Between DC Sources
Simplifies Load Sharing with Multiple Batteries
Low Quiescent Current: 11μA
3V to 28V AC/DC Adapter Voltage Range
2.5V to 28V Battery Voltage Range
Reverse Battery Protection
Drives Almost Any Size MOSFET for Wide Range of Current Requirements
MOSFET Gate Protection Clamp
Manual Control Input
Low Profile (1mm) ThinSOT™ Package

Applications Of LTC4412IS6
Cellular Phones
Notebook and Handheld Computers
Digital Cameras
USB-Powered Peripherals
Uninterruptible Power Supplies
Logic Controlled Power Switch
