Product Description Of TPA3100D2PHP
TPA3100D2PHP is a 20-W (per channel) efficient, Class-D audio power amplifier for driving bridged-tied stereo speakers. The TPA3100D2PHP can drive stereo speakers as low as 4Ω . The high efficiency of the TPA3100D2PHP, 92%, eliminates the need for an external heat sink when playing music.
Specification Of TPA3100D2PHP
2-Channel Stereo
Class-D
21.8 W
0.11 %
HTQFP-48
8 Ohms
10 V
26 V
- 40 C
+ 85 C
Dual Supply Voltage:
12 V, 15 V, 18 V, 24 V
Gain:
36 dB
Height:
1 mm
Input Type:
Analog
Length:
7 mm
Maximum Dual Supply Voltage:
26 V
Minimum Dual Supply Voltage:
10 V
Moisture Sensitive:
Yes
Number of Channels:
2 Channel
Operating Supply Current:
18 mA
Operating Supply Voltage:
12 V, 15 V, 18 V, 24 V
Output Signal Type:
Differential
Pd - Power Dissipation:
5 W
PSRR - Power Supply Rejection Ratio:
70 dB
Subcategory:
Audio ICs
Supply Type:
Single
Type:
2-Channel Stereo
Width:
7 mm
Unit Weight:
134.500 mg
Features Of TPA3100D2PHP
20-W/ch into an 8-Ω Load From a 18-V Supply
10-W/ch into an 8-Ω Load From a 12-V Supply
15-W/ch into an 4-Ω Load From a 12-V Supply
Operates from 10 V to 26 V
92% Efficient Class-D Operation Eliminates Need for Heat Sinks
Four Selectable, Fixed Gain Settings
Differential Inputs
Thermal and Short-Circuit Protection With Auto Recovery Feature
Clock Output for Synchronization With Multiple Class-D Devices
Applications Of TPA3100D2PHP
Televisions
