TPS2592ZADRCR Integrated Circuit Chip eFuse IC VSON10 Electronic Fuse Regulator

TPS2592ZADRCR Integrated Circuit Chip eFuse IC VSON10 Electronic Fuse Regulator

Product Overviews Of TPS2592ZADRCR

TPS2592ZADRCR is 4.5V to 18V eFuse with Blocking FET Control. It is a highly integrated circuit protection and power management solution in a tiny package.
TPS2592ZADRCR use few external components and provide multiple protection modes. It is a robust defense against overloads, shorts circuits, voltage surges, excessive inrush current, and reverse current.

Specification Of TPS2592ZADRCR

Features Of TPS2592ZADRCR

4.5V to 18V Protection
Integrated 28mΩ Pass MOSFET
Absolute Maximum Voltage of 20V
1A to 2.1A Adjustable ILIMIT
Reverse Current Blocking Support
Programmable OUT Slew Rate, UVLO
Built-in Thermal Shutdown
Safe during Single Point Failure Test (UL60950)
Small Foot Print – 10L (3 mm × 3 mm) VSON

Applications Of TPS2592ZADRCR

HDD and SSD Drives
Set Top Boxes
Servers / AUX Supplies
Fan Control
PCI/PCIe Cards
Adapter Powered Devices

Application Schematic Of TPS2592ZADRCR
