TDA5252 Wireless Communication Module Low Power ASK/FSK 915MHz Wireless Transceiver

TDA5252 Wireless Communication Module Low Power ASK/FSK 915MHz Wireless Transceiver

Product Description Of TDA5252
TDA5252 is a low power consumption single chip FSK/ASK Transceiver for half duplex low datarate communication in the 915MHz band. The IC offers a very high level of integration and needs only a few external components. It contains a highly efficient power amplifier, a low noise amplifier (LNA) with AGC, a double balanced mixer, a complex direct conversion stage, |/Q limiters with RSSI generation, an FSK demodulator, a fully integrated VCO and PLL synthesizer, a tuneable crystal oscillator, an onboard data filter, a data comparator (slicer), positive and negative peak detectors, a data rate detection circuit and a 2/3-wire bus interface. Additionally there is a power down feature to save battery power.

Specification Of TDA5252

Features Of TDA5252
Low supply current (Is = 9mA typ. receive, Is = 13mA typ. transmit mode)
Supply voltage range 2.1 - 5.5V
Power down mode with very low supply current consumption
FSK and ASK modulation and demodulation capability
Fully integrated VCO and PLL synthesizer and loop filter on-chip with on chip crystal oscillator tuning
I2C/3-wire µController Interface
On-chip low pass channel select filter and data filter with tuneable bandwidth
Data slicer with self-adjusting threshold and 2 peak detectors
FSK sensitivity < -109dBm, ASK sensitivity < -109dBm
Transmit power up to +13dBm
Self-polling logic with ultra fast data rate detection

Applications Of TDA5252

Low Bitrate Communication Systems
Keyless Entry Systems
Remote Control Systems
Alarm Systems
Telemetry Systems
Electronic Metering
Home Automation Systems
