IR2304STRPBF Integrated Circuit Chip Half Bridge Gate Driver IC SOIC8 PMIC Chip

IR2304STRPBF Integrated Circuit Chip Half Bridge Gate Driver IC SOIC8 PMIC Chip​

Product Overviews Of IR2304STRPBF

IR2304STRPBF is a high voltage, high speed power MOSFET and IGBT driver with independent high and low side referenced output channels. Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction.

Specification Of IR2304STRPBF

Features Of IR2304STRPBF

Floating channel designed for bootstrap operation to +600V. Tolerant to negative transient voltage dV/dt immune
Gate drive supply range from 10 to 20V
Under voltage lockout for both channels
3.3V, 5V, and 15V input logic input compatible
Cross-conduction prevention logic
Matched propagation delay for both channels
Lower di/dt gate driver for better noise immunity
Internal 100ns dead-time
Output in phase with input

Block Diagram Of IR2304STRPBF


Other Electronic Components In Stock

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
