RTL8111F-CGT Ethernet IC Integrated Gigabit Ethernet Controller QFN48 Ethernet Chip

RTL8111F-CGT Ethernet IC Integrated Gigabit Ethernet Controller QFN48 Ethernet Chip

Product Description Of RTL8111F-CGT

RTL8111F-CGT is 10/100/1000M Ethernet controller, it combines a triple-speed IEEE 802.3 compatible Media Access Controller (MAC) with a triple-speed Ethernet transceiver, PCI Express bus controller, and embedded memory.

Features Of RTL8111F-CGT

Integrated 10/100/1000 transceiver
Auto-Negotiation with Next Page capability
Supports PCI Express 1.1
Supports pair swap/polarity/skew correction
Crossover Detection & Auto-Correction
Wake-on-LAN and remote wake-up support
Microsoft NDIS5, NDIS6 Checksum Offload (IPv4, IPv6, TCP, UDP) and Segmentation Task-offload (Large
send v1 and Large send v2) support
Supports EMAC-393 ECMA ProxZzzy Standard for sleeping hosts
Supports Full Duplex flow control (IEEE 802.3x)
Supports jumbo frame to 9K bytes
Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Supports IEEE 802.1P Layer 2 Priority Encoding
Supports IEEE 802.1Q VLAN tagging
Supports IEEE 802.3az-2010 (EEE)
Embedded OTP memory can replace the external EEPROM
Serial EEPROM
Transmit/Receive on-chip buffer support
Supports power down/link down power saving/PHY disable mode
Built-in switching regulator
Supports PCI MSI (Message Signaled Interrupt) and MSI-X
Supports quad core Receive-Side Scaling (RSS)
Supports Protocol Offload (ARP & NS)
Supports Customized LEDs
Supports 1-Lane 2.5Gbps PCI Express Bus
Supports hardware ECC (Error Correction Code) function
Supports hardware CRC (Cyclic Redundancy Check) function
48-pin QFN ‘Green’ package

Applications Of RTL8111F-CGT

PCI Express 10/100/1000M Ethernet on Motherboard, Notebook, or Embedded system
