AD8422BRMZ Integrated Circuit Chip Rail To Rail Instrumentation Amplifiers MSOP8

AD8422BRMZ Integrated Circuit Chip Rail To Rail Instrumentation Amplifiers MSOP8​

Product Description Of AD8422BRMZ

AD8422BRMZ is a high precision, low power, low noise, rail-to-rail instrumentation amplifier that delivers the best performance per unit microampere in the industry. The AD8422BRMZprocesses signals with ultralow distortion performance that is load independent over its full output range.

Specification Of AD8422BRMZ

Features Of AD8422BRMZ

Low power: 368 μA maximum quiescent current
Rail-to-rail output
Low noise and distortion
- 8nV/√Hz maximum input voltage noise at 1 kHz
- 0.15μV p-p RTI noise (G = 100)
- 0.5ppm nonlinearity with 2 kΩ load (G = 1)
Excellent ac specifications
- 80dB minimum CMRR at 10 kHz (G = 1)
- 2.2MHz bandwidth (G = 1)
Wide supply range
- 4.6 V to 36 V single supply
- ±2.3 V to ±18 V dual supply
Input overvoltage protection: 40 V from opposite supply
Gain range: 1 to 1000

Applications Of AD8422BRMZ

Medical instrumentation
Industrial process controls
Strain gages
Transducer interfaces
Precision data acquisition systems
Channel-isolated systems
Portable instrumentatio
