TLE5014P16 Sensor IC XENSIV Magnetic Angle Sensor PG-TDSO-16 GMR Based Angle Sensor

TLE5014P16 Sensor IC XENSIV Magnetic Angle Sensor PG-TDSO-16 GMR Based Angle Sensor

Product Description Of TLE5014P16

TLE5014P16 is XENSIV™magnetic angle sensor, highest functional safety grading, easy-to-use. It is designed for angular position sensing in automotive applications with focus on steering angle sensor.

Specification Of TLE5014P16

Features Of TLE5014P16

Giant Magneto Resistance (GMR)-based principle
Integrated magnetic field sensing for angle measurement
360° angle measurement
High voltage and reverse polarity capability
12 bit representation of absolute angle value on the output
Max. 1° angle error over lifetime and temperature range
Internal safety mechanisms with a SPFM > 97%
Interfaces: PWM, SPC, SENT (based on SAE J2716-2010)
32 point look-up table to correct for systematic angle errors (e.g. magnetic circuit)
112 bit customer ID (programmable)
Automotive qualified Q100, Grade 1: -40°C to 125°C (ambient temperature)
ESD: 4kV (HBM) on VDD and output pin

Applications Of TLE5014P16
Steering angle sensor
Pedal position
Chassis
Smart actuator
Valve position
Safety-related absolute rotary position application
Automotive secondary power distribution unit
Domain controller for ADAS and autonomous driving
