LMZ14201TZX-ADJ Integrated Circuit Chip 1A SIMPLE SWITCHER Power Module TO-PMOD-7

LMZ14201TZX-ADJ Integrated Circuit Chip 1A SIMPLE SWITCHER Power Module TO-PMOD-7​

Product Description Of LMZ14201TZX-ADJ

LMZ14201TZX-ADJ is 6V to 42V, 1A, SIMPLE SWITCHER® Power Module in Leaded Surface Mount TO Package.

LMZ14201TZX-ADJ is an easy-to-use step-down DC-DC solution that can drive up to 1-A load with exceptional power conversion efficiency, line and load regulation, and output accuracy. The LMZ14201TZX-ADJ is available in an innovative package that enhances thermal performance and allows for hand or machine soldering.

Specification Of LMZ14201TZX-ADJ

Features Of LMZ14201TZX-ADJ

Integrated Shielded Inductor
Simple PCB Layout
Flexible Start-Up Sequencing Using External Soft-Start and Precision Enable
Protection Against Inrush Currents and Faults Such as Input UVLO and Output Short Circuit
–40°C to 125°C Junction Temperature Range
Single Exposed Pad and Standard Pinout for Easy Mounting and Manufacturing
Fast Transient Response for Powering FPGAs
Low Output Voltage Ripple
Pin-to-Pin Compatible Family: LMZ1420x (42 V Maximum 3 A, 2 A, 1 A)
Fully Enabled for WEBENCH Power Designer
Electrical Specifications
- 6W Maximum Total Output Power
- Up to 1A Output Current
- Input Voltage Range 6 V to 42 V
- Output Voltage Range 0.8 V to 6 V
- Efficiency up to 90%
Performance Benefits
- Operates at High Ambient Temperature With No Thermal Derating
- High Efficiency Reduces System Heat Generation
- Low Radiated Emissions (EMI) Tested With EN55022 Class B Standard
- Low External Component Count

Applications Of LMZ14201TZX-ADJ

Point of Load Conversions From 12V and 24V Input Rail
Time-Critical Projects
Space Constrained and High Thermal Requirement Applications
Negative Output Voltage Applications
