Products Description Of 88E6060-B0-RCJ1I000
88E6060-B0-RCJ1I000 is a single chip integration of a complete 6-port Fast Ethernet switch with support for a CPU connection. It contains five 10BASE-T/100BASE-TX transceivers (PHYs), two that can be used to sup-port 100BASE-FX; six independent Fast Ethernet media access controllers (MACs), a high-speed non-blocking switch fabric, a high-performance address lookup engine, and a 1/2 megabit frame buffer mem-ory. It is designed for cost-sensitive low port count switch systems and firewall routers

Feature Of 88E6060-B0-RCJ1I000
Single chip integration of a 6-port Fast Ethernet switch in a 14x20 mm 128-pin PQFP package
Integrates six independent media access control-lers fully compliant with the applicable sections of IEEE802.3
Integrates five independent Fast Ethernet PHY transceivers fully compliant with the applicable sections of IEEE802.3
Supports 802.1X implementation with Port-based access control
Port based VLANs supported in any combination
Supports a CPU header mode for accelerated router performance and wirespeed VLAN control
Port States & BPDU handling supports Spanning Tree
Automatic MDI/MDIX crossover for 100BASE-TX and 10BASE-T ports
Port 0 and Port 1 can be configured as copper (100BASE-TX or 10BASE-T) or fiber (100BASE-FX)
Port 5 has dedicated, always on, MAC Mode (For-ward) or PHY Mode (Reverse) RMII/MII/SNI inter-face for management and firewall applications
Port 4 can be either a copper (100BASE-TX or 10BASE-T) or an MII interface with the same interface options as Port 5
Each port works at 10 Mbps or 100 Mbps, full-duplex or half-duplex mode (forced or auto-negotiated)
Back-pressure flow control on half-duplex ports & Pause-frame flow control on full-duplex ports
Shared on-chip memory-based switch fabric with true non-blocking switching performance
High performance lookup engine with support for up to 1,024 MAC address entries with automatic learning and aging
Flexible LED support for Link, Speed, Duplex Mode, Collision, and Tx/Rx Activities
Supports a low cost 25 MHz XTAL clock source or a 25 MHz or 50 MHz OSC.
Pin compatible with the Marvell® 88E6063, 88E6061, 88E6065, 88E6031, and 88E6035
Low power dissipation PAVE = Less than 0.6W
Available with Commercial grade (88E6060 part) or Industrial grade (88E6060-I part) temperature specifications
Integrates Virtual Circuit Tester™ (VCT™) with each Marvell PHY

Applications Of 88E6060-B0-RCJ1I000
Firewall Router Switch w/four 10/100BASE-T LAN ports & one 10/100BASE-T WAN port
Five port Switch with Spanning Tree Support
Firewall Router Switch supporting a Fiber WAN port
Fiber to Copper Industrial Temperature media converter
Four-port LAN switch with two MII connections for WAN PHY and wireless interface
