AD7468BRTZ Integrated Circuit Chip 8Bit ADC Converters 1.6V Analog To Digital Converter

AD7468BRTZ Integrated Circuit Chip 8Bit ADC Converters 1.6V Analog To Digital Converter​

Product Description Of AD7468BRTZ

AD7468BRTZ is 8-bit, high speed, low power, successive approximation analog-to-digital converters (ADCs), respectively. AD7468BRTZ operate from a single 1.6 V to 3.6 V power supply and feature throughput rates up to 200 kSPS with low power dissipation. The AD7468BRTZ contain a low noise, wide bandwidth track-and-hold amplifier, which can handle input frequencies in excess of 3 MHz.

Specification Of AD7468BRTZ

Features Of AD7468BRTZ

Specified for VDD of 1.6 V to 3.6 V
Low power:
- 0.62 mW typical at 100 kSPS with 3 V supplies
- 0.48 mW typical at 50 kSPS with 3.6 V supplies
- 0.12 mW typical at 100 kSPS with 1.6 V supplies
Wide input bandwidth: 71 dB SNR at 30 kHz input frequency
Fast throughput rate: 200 kSPS
Flexible power/serial clock speed management
No pipeline delays
High speed serial interface: SPI/QSPI™/MICROWIRE™/DSP compatible

Applications Of AD7468BRTZ

Battery-powered systems
Medical instruments
Remote data acquisition
Isolated data acquisition
