KSZ8081RNAIA Ethernet IC 10/100 Base-T/TX Physical Layer Transceiver With RMII Support
KSZ8081RNAIA Ethernet IC 10/100 Base-T/TX Physical Layer Transceiver With RMII Support
Description
Part Number:
KSZ8081RNAIA
Standard::
10BASE-T, 100BASE-TX
Number Of Transceivers::
1 Transceiver
Data Rate::
10 Mb/s, 100 Mb/s
Interface Type::
MII, RMII
Supply Current - Max::
47 MA
Highlight:
KSZ8081RNAIA
,
KSZ8081RNAIA Ethernet IC
,
10/100 Base-T/TX Physical Layer Transceiver
KSZ8081RNAIA Ethernet IC 10/100 Base-T/TX Physical Layer Transceiver With RMII Support
Product Description Of KSZ8081RNAIA
KSZ8081RNAIA is a single-supply 10Base-T/100Base-TX Ethernet physical-layer transceiver for transmission and reception of data over standard CAT-5 unshielded twisted pair (UTP) cable. The KSZ8081RNAIA is a highly-integrated PHY solution. It reduces board cost and simplifies board layout by using on-chip termination resistors for the differential pairs and by integrating a low-noise regulator to supply the 1.2V core, and by offering 1.8/2.5/3.3V digital I/O interface support.
Specification Of KSZ8081RNAIA
10BASE-T, 100BASE-TX
1 Transceiver
10 Mb/s, 100 Mb/s
MII, RMII
3.135 V
3.465 V
- 40 C
+ 85 C
Duplex:
Full Duplex, Half Duplex
Moisture Sensitive:
Yes
Product Type:
Ethernet ICs
Supply Current - Max:
47 mA
Unit Weight:
1 g
Feature Of KSZ8081RNAIA
Single-chip 10Base-T/100Base-TX IEEE 802.3 compliant Ethernet transceiver
MII interface support (KSZ8081MNX)
RMII v1.2 Interface support with a 50MHz reference clock output to MAC, and an option to input a 50MHz reference clock (KSZ8081RNB)
RMII back-to-back mode support for a 100Mbps copper repeater
MDC/MDIO management interface for PHY register configuration
Programmable interrupt output
LED outputs for link and activity status indication
On-chip termination resistors for the differential pairs
Baseline wander correction
HP Auto MDI/MDI-X to reliably detect and correct straight-through and crossover cable connections with disable and enable option
Auto-negotiation to automatically select the highest linkup speed (10/100Mbps) and duplex (half/full)
Power-down and power-saving modes
LinkMD® TDR-based cable diagnostics to identify faulty copper cabling
Parametric NAND Tree support for fault detection between chip I/Os and the board
Loopback modes for diagnostics
Single 3.3V power supply with VDD I/O options for 1.8V, 2.5V, or 3.3V
Application Of KSZ8081RNAIA
Game Consoles
IP Phones
IP Set-Top Boxes
IP TVs
LOM
Printers
