L6229D Integrated Circuit Chip DMOS Driver 3-Phase Brushless DC Motor Driver SOIC24

L6229D Integrated Circuit Chip DMOS Driver 3-Phase Brushless DC Motor Driver SOIC24​

Product Description Of L6229D

L6229D is a DMOS fully integrated 3-phase motor driver with overcurrent protection. Realized in BCD technology, L6229D combines isolated DMOS power transistors with CMOS and bipolar circuits on the same chip.

L6229D includes all the circuitry needed to drive a 3-phase BLDC motor including: a 3-phase DMOS bridge, a constant off time PWM current controller and the decoding logic for single ended Hall sensors that generates the required sequence for the power stage.

Specification Of L6229D

Features Of L6229D

Operating supply voltage from 8 to 52 V
2.8 A output peak current (1.4 A DC)
RDS(ON) 0.73 Ω typ. value at Tj = 25 °C
Operating frequency up to 100 kHz
Non-dissipative overcurrent detection and protection
Diagnostic output
Constant tOFF PWM current controller
Slow decay synchronous rectification
60° and 120° Hall effect decoding logic
Brake function
Tachometer output for speed loop
Cross conduction protection
Thermal shutdown
Undervoltage lockout
Integrated fast free wheeling diodes

Applications Of L6229D
Factory automation end-points
Home appliances
Small pumps
ATMs
