UCC25710DWR Integrated Circuit Chip LLC Half Bridge Controller SOIC20 LED Lighting Drivers

Large Image : UCC25710DWR Integrated Circuit Chip LLC Half Bridge Controller SOIC20 LED Lighting Drivers

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	UCC25710DWR

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	SOIC-20
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

UCC25710DWR Integrated Circuit Chip LLC Half Bridge Controller SOIC20 LED Lighting Drivers

Description

Part Number:	UCC25710DWR	Voltage - Supply (Min):	11V
Voltage - Supply (Max):	18V	Dimming:	PWM
Applications:	Backlight, Lighting	Operating Temperature:	-40°C ~ 125°C (TA)
Highlight:	UCC25710DWR , UCC25710DWR Integrated Circuit Chip , SOIC20 LED Lighting Drivers

UCC25710DWR Integrated Circuit Chip LLC Half Bridge Controller SOIC20 LED Lighting Drivers

Product Description Of UCC25710DWR

UCC25710DWR is an LLC half-bridge controller for accurate control of multi-string LED backlight applications. UCC25710DWR is optimized for multi-transformer, multi-string LED architectures. Superior LED current matching in multiple strings can be achieved with this controller and architecture. Compared to existing LED backlight solutions, the multi-transformer architecture provides the highest overall efficiency from AC input to LED load.

Specification Of UCC25710DWR

Part Number:	UCC25710DWR
Product Category:	LED Lighting Driver ICs
Mounting Style:	SMD/SMT
Package / Case:	SOIC-20
Number of Outputs:	1 Output
Output Current:	800 mA
Minimum Operating Temperature:	- 40 ℃
Maximum Operating Temperature:	+ 125 ℃
Features:	LED Open Detection, Soft Start
Number of Channels:	1 Channel
Product Type:	LED Lighting Drivers

Features Of UCC25710DWR

Closed-Loop LED String Current Control

PWM Dimming Input
Adjustable FMIN (3% accuracy), and FMAX (7.5% Accuracy)
LLC and Series LED Switch Control for Dimming
Programmable Dimming LLC ON/OFF Ramp for Elimination of Audible Noise
Closed-Loop Current Control at Low Dimming Duty Cycles
Programmable Soft Start
Accurate VREF for Tight Output Regulation
Overvoltage, Undervoltage and Input Overcurrent Protection With Auto-Restart Response
Second Overcurrent Threshold With Latch-Off Response
400-mA/-800-mA Gate Drive Current
Low Start-Up and Operating Currents
Lead (Pb)-Free, 20-Pin, SOIC Package

Applications Of UCC25710DWR
LED Backlight for LCD TV and Monitors
LED General Lighting
