NCV7720DQAR2G Integrated Circuit Chip Ten Channel Half-Bridge Driver With Protection Features

NCV7720DQAR2G Integrated Circuit Chip Ten Channel Half-Bridge Driver With Protection Features

Product Description Of NCV7720DQAR2G
NCV7720DQAR2G is a ten channel half-bridge driver with protection features designed specifically for automotive and industrial motion control applications. The product has independent controls and diagnostics, and the drivers can be operated in forward, reverse, brake, and high impedance states. The device is controlled via a 16 bit SPI interface and is daisy chain compatible.

Specification Of NCV7720DQAR2G

Feature Of NCV7720DQAR2G
Low Quiescent Current Sleep Mode
HighSide and LowSide Drivers Connected in a HalfBridge Configuration
Integrated Freewheeling Protection (LS and HS)
0.55 A Peak Current
RDS(on) = 1 ohm (typ)
5 MHz SPI Control
Compliance with 5 V and 3. 3 V Systems
Undervoltage and Overvoltage Lockout
Overcurrent Protection
Overtemperature Protection
Under Load Detection
Discriminated Fault Reporting
16Bit Frame Detection
Daisy Chain Compatible with Multiple of 8 bit Devices

Applications Of NCV7720DQAR2G
Automotive
Industrial
DC Motor Management for HVAC Application
