AD8139ARDZ is an ultralow noise, high performance differential amplifier with rail-to-rail output. With its low noise, high SFDR, and wide bandwidth, it is an ideal choice for driving analog-to-digital converters (ADCs) with resolutions to 18 bits. The AD8139ARDZ is easy to apply, and its internal common-mode feedback architecture allows its output common-mode voltage to be controlled by the voltage applied to one pin. The internal feedback loop also provides outstanding output balance as well as suppression of even-order harmonic distortion products. Fully differential and single-ended-to-differential gain configurations are easily realized by the AD8139ARDZ. Simple external feedback networks consisting of four resistors determine the closed-loop gain of the amplifier.
Specification Of AD8139ARDZ
1 Channel
410 MHz
800 V/us
84 dB
100 mA
8 uA
150 uV
12 V
5 V
24.5 mA
- 40 C
+ 125 C
Gain V/V:
1 V/V
Input Voltage Range - Max:
3.8 V
Maximum Input Resistance:
3.5 MOhms
Moisture Sensitive:
Yes
Operating Supply Voltage:
4.5 V to 6 V
PSRR - Power Supply Rejection Ratio:
109 dB
Settling Time:
45 ns
Unit Weight:
540 mg
Features Of AD8139ARDZ
Fully differential
Low noise
2.25 nV/√Hz
2.1 pA/√Hz
Low harmonic distortion
98 dBc SFDR at 1 MHz
85 dBc SFDR at 5 MHz
72 dBc SFDR at 20 MHz
High speed
410 MHz, 3 dB BW (G = 1)
800 V/µs slew rate
45 ns settling time to 0.01%
69 dB output balance at 1 MHz
80 dB dc CMRR
Low offset: ±0.5 mV maximum
Low input offset current: 0.5 µA maximum
Differential input and output
Differential-to-differential or single-ended-to-differential operation
Rail-to-rail output
Adjustable output common-mode voltage
Wide supply voltage range: 5 V to 12 V
Available in a small SOIC package and an 8-lead LFCSP
Applications Of AD8139ARDZ
ADC drivers to 18 bits
Single-ended-to-differential converters
Differential filters
Level shifters
Differential PCB drivers
Differential cable drivers
