TLV3541IDBVR Integrated Circuit Chip 200MHz Operational Amplifier SOT-23-5 Op Amps IC

TLV3541IDBVR Integrated Circuit Chip 200MHz Operational Amplifier SOT-23-5 Op Amps IC​​

Product Description Of TLV3541IDBVR

TLV3541IDBVR is single-channel, low-power (5.2-mA per channel), high-speed, unity-gain stable, rail-to-rail input/output operational amplifiers (op amps) designed for video and other applications that require wide bandwidth.

Specification Of TLV3541IDBVR

Features Of TLV3541IDBVR

Wide-Bandwidth Amplifier for Cost-Sensitive Systems
Unity-Gain Bandwidth: 200 MHz
High Slew Rate: 150 V/µs
Low Noise: 7.5 nV/√Hz
Rail-to-Rail I/O
High Output Current: > 100 mA
Excellent Video Performance:
Diff Gain: 0.02%, Diff Phase: 0.09°
0.1-dB Gain Flatness: 40 MHz
Low Input Bias Current: 3 pA
Quiescent Current: 5.2 mA
Thermal Shutdown
Supply Range: 2.5 V to 5.5 V

Applications Of TLV3541IDBVR
High-Resolution ADC Driver Amplifiers
IR Touch
Low-Voltage, High-Frequency Signal Processing
Video Processing
Base Transceiver Stations
Optical Networking, Tunable Lasers
Photodiode Transimpedance Amplifiers
Barcode Scanners
Fast Current-Sensing Amplifiers
Ultrasound Imaging
