LIS3MDLTR Sensor IC Ultra-Low-Power High-Performance 3-Axis Magnetic Sensor
LIS3MDLTR Sensor IC Ultra-Low-Power High-Performance 3-Axis Magnetic Sensor
Description
Part Number:
LIS3MDLTR
Operating Supply Current::
270 UA
Operating Point Min/Max::
+/- 4 G, +/- 8 G, +/- 12 G, +/- 16 G
Operating Supply Voltage::
3 V
Minimum Operating Temperature::
- 40 C
Maximum Operating Temperature::
+ 85 C
LIS3MDLTR Sensor IC Ultra-Low-Power High-Performance 3-Axis Magnetic Sensor
Product Description Of LIS3MDLTR
LIS3MDLTR is an ultralow-power high-performance 3-axis magnetic sensor with user-selectable full scales of ±4/±8/±12/±16 gauss.
The self-test capability allows the user to check the functioning of the sensor in the final application.
The device may be configured to generate interrupt signals for magnetic field detection.
The LIS3MDLTR includes an I²C serial bus interface that supports standard and fast mode (100 kHz and 400 kHz) and SPI serial standard interfaces.
The device is available in a small thin plastic, land grid array (LGA) package and is guaranteed to operate over an extended temperature range of -40°C to +85°C.
Specification Of LIS3MDLTR
Magnetic
270 uA
+/- 4 G, +/- 8 G, +/- 12 G, +/- 16 G
3 V
- 40 C
+ 85 C
Supply Voltage - Max:
3.6 V
Supply Voltage - Min:
1.9 V
Unit Weight:
78 mg
Feature Of LIS3MDLTR
Wide supply voltage, 1.9 V to 3.6 V
Independent IO supply (1.8 V)
±4/±8/±12/±16 gauss selectable magnetic full scales
Continuous and single-conversion modes
16-bit data output
Interrupt generator
Self-test
I²C/SPI digital output interface
Power-down mode / low-power mode
ECOPACK and RoHS compliant
Applications Of LIS3MDLTR
Magnetometers
Compasses
