Product Details:
|
Part Number: | LT6654AHS6-2.5 | Output Voltage:: | 2.5 V |
---|---|---|---|
Initial Accuracy:: | 0.05 % | Temperature Coefficient:: | 10 PPM / C |
Series VREF - Input Voltage - Max:: | 36 V | Shunt Current - Max:: | 600 UA |
LT6654AHS6-2.5 Integrated Circuit Chip Precision Wide Supply High Output Drive Low Noise Reference
Product Description Of LT6654AHS6-2.5
LT6654AHS6-2.5 is a small precision voltage references that offers high accuracy, low noise, low drift, low dropout and low power. The LT6654AHS6-2.5 operates from voltages up to 36V and is fully specified from –55°C to 125°C. A buffered output ensures ±10mA of output drive with low output impedance and precise load regulation. These features, in combination, make the LT6654AHS6-2.5 ideal for portable equipment, industrial sensing and control, and automotive applications.
Specification Of LT6654AHS6-2.5
|
2.5 V |
|
0.05 % |
|
10 PPM / C |
|
36 V |
|
600 uA |
|
- 40 C |
|
+ 125 C |
Height: |
1 mm |
Unit Weight: |
12.543 mg |
Features Of LT6654AHS6-2.5
Low Drift:
A-Grade: 10ppm/°C Max
B-Grade: 20ppm/°C Max
High Accuracy:
A-Grade: ±0.05% Max
B-Grade: ±0.10% Max
Low Noise: 1.6ppmP-P (0.1Hz to 10Hz)
Wide Supply Range to 36V
Low Thermal Hysteresis: LS8 15ppm (–40°C to 125°C)
Long Term Drift: (LS8) 15ppm/√kHr
Line Regulation (Up to 36V): 5ppm/V Max
Low Dropout Voltage: 100mV Max
Sinks and Sources ±10mA
Load Regulation at 10mA: 8ppm/mA Max
Fully Specified from -55°C to 125°C
Available Output Voltage Options: 1.25V, 2.048V, 2.5V, 3V, 3.3V, 4.096V, 5V
Low Profile (1mm) ThinSOT™ Package and 5mm × 5mm Surface Mount Hermetic Package
AEC-Q100 Qualified for Automotive Applications
Applications Of LT6654AHS6-2.5
Automotive Control and Monitoring
High Temperature Industrial
High Resolution Data Acquisition Systems
Instrumentation and Process Control
Precision Regulators
Medical Equipment
