SN75LVPE5412RUAR Integrated Circuit Chip PCIe 5.0 32Gbps 4-Channel Linear Redriver

SN75LVPE5412RUAR Integrated Circuit Chip PCIe 5.0 32Gbps 4-Channel Linear Redriver

Product Description Of SN75LVPE5412RUAR
The SN75LVPE5412 is a four channel linear redriver with integrated demultiplexer (demux). The low-power high-performance linear redriver is designed to support PCIe 5.0 and other interfaces up to 32Gbps.

Specification Of SN75LVPE5412RUAR

Features Of SN75LVPE5412RUAR
Quad channel PCIe 5.0 linear redriver or repeater with integrated 1:2 demultiplexer
Protocol agnostic linear redriver compatible to PCIe, UPI, CCIX, NVLink, DisplayPort, SAS, SATA, and XFI
Single 3.3V supply – PCIe power rail can be used
Low 720mW active power for 4-channel operation
No heat sink required
Provides equalization up to 24dB at 16GHz
Excellent RX/TX differential RL of -10dB for 8-16GHz
Low additive RJ of 55 fs RMS with PRBS data
Low latency of 90ps
Automatic receiver detection and seamless support for PCIe link training
Device configuration by pin control or SMBus / I2C.
Demux selection through pin
Internal voltage regulator provides immunity to supply noise
High speed production testing for reliable manufacturing
Support for x4, x8, and x16 bus width with one or multiple device
Available companion multiplexer product SN75LVPE5421
-40°C to 85°C temperature range
3.5 × 9mm 42 Pin 0.5mm pitch WQFN package

Application Of SN75LVPE5412RUAR
Desktop PC and motherboard
Display panel, gaming console
Rack server, microserver, and tower server
High performance computing, hardware accelerator
Data storage, network attached storage
Storage area network (SAN) and host bus adapter (HBA) card
Network interface card (NIC)
