LM5118MHX Integrated Circuit Chip Wide Voltage Range Buck-Boost Controller

LM5118MHX Integrated Circuit Chip Wide Voltage Range Buck-Boost Controller

Product Description Of LM5118MHX
LM5118MHX wide voltage range Buck-Boost switching regulator controller features all of the functions necessary to implement a high-performance, cost-efficient Buck-Boost regulator using a minimum of external components. The Buck-Boost topology maintains output voltage regulation when the input voltage is either less than or greater than the output voltage, making it especially suitable for automotive applications. The LM5118MHX operates as a buck regulator while the input voltage is sufficiently greater than the regulated output voltage and gradually transitions to the buck-boost mode as the input voltage approaches the output. This dual-mode approach maintains regulation over a wide range of input voltages with optimal conversion efficiency in the buck mode and a glitch-free output during mode transitions. This easy-to-use controller includes drivers for the high-side buck MOSFET and the low-side boost MOSFET. The regulators control method is based upon current mode control using an emulated current ramp. Emulated current mode control reduces noise sensitivity of the pulse-width modulation circuit, allowing reliable control of the very small duty cycles necessary in high input voltage applications. Additional protection features include current limit, thermal shutdown and an enable input. The device is available in a power-enhanced, 20-pin HTSSOP package featuring an exposed die attach pad to aid thermal dissipation.

Specification Of LM5118MHX

Features Of LM5118MHX
Ultra-Wide Input Voltage Range From 3 V to 75 V
Emulated Peak Current Mode Control
Smooth Transition Between Step-Down and Step-Up Modes
Switching Frequency Programmable to 500 KHz
Oscillator Synchronization Capability
Internal High Voltage Bias Regulator
Integrated High and Low-Side Gate Drivers
Programmable Soft-Start Time
Ultra-Low Shutdown Current
Enable Input Wide Bandwidth Error Amplifier
1.5% Feedback Reference Accuracy
Thermal Shutdown
Package: 20-Pin HTSSOP (Exposed Pad)

Application Of LM5118MHX
Industrial Buck-Boost Supplies

Other Supply Product Types
