CSD95492QVM Integrated Circuit Chip Synchronous Buck NexFET™ Smart Power Stage
CSD95492QVM Integrated Circuit Chip Synchronous Buck NexFET™ Smart Power Stage
Description
Part Number:
CSD95492QVM
Switching Frequency::
1.25 MHz
Duty Cycle - Max::
85 %
Output Voltage::
5.5 V
Output Current::
20 A
Operating Supply Voltage::
4.5 V To 16 V
Highlight:
CSD95492QVM
,
CSD95492QVM Integrated Circuit Chip
CSD95492QVM Integrated Circuit Chip Synchronous Buck NexFET™ Smart Power Stage
Product Description Of CSD95492QVM
CSD95492QVM NexFET™ power stage is a highly optimized design for use in a high-power, highdensity synchronous buck converter. This product integrates the driver IC and power MOSFETs to complete the power stage switching function. This combination produces high-current, high-efficiency, and high-speed switching capability in a small 4-mm × 5-mm outline package. It also integrates the accurate current sensing and temperature sensing functionality to simplify system design and improve accuracy. In addition, the PCB footprint has been optimized to help reduce design time and simplify the completion of the overall system design.
Specification Of CSD95492QVM
1 Output
1.25 MHz
85 %
5.5 V
20 A
- 55 C
+ 150 C
Moisture Sensitive:
Yes
Operating Supply Voltage:
4.5 V to 16 V
Unit Weight:
90.100 mg
Features Of CSD95492QVM
20-A Continuous Operating Current Capability
Over 94% System Efficiency at 12 A
High-Frequency Operation (up to 1.25 MHz)
Diode Emulation Function
Temperature Compensated Bi-Directional Current Sense
Analog Temperature Output
Fault Monitoring
3.3-V and 5-V PWM Signal Compatible
Tri-State PWM Input
Integrated Bootstrap Switch
Optimized Dead Time for Shoot-Through Protection
High-Density VSON 4-mm × 5-mm Footprint
Ultra-Low-Inductance Package
System Optimized PCB Footprint
RoHS Compliant – Lead-Free Terminal Plating
Halogen Free
Applications Of CSD95492QVM
Multiphase Synchronous Buck Converters
High-Frequency Applications
High-Current, Low-Duty Cycle Applications
POL DC-DC Converters
Memory and Graphic Cards
Desktop and Server VR12.x / VR13.x VRM Synchronous Buck Converters
