SI8660BD-ASR Integrated Circuit Chip 5000Vrms Six Channel Digital Isolators SOIC16

SI8660BD-ASR Integrated Circuit Chip 5000Vrms Six Channel Digital Isolators SOIC16​

Product Description Of SI8660BD-ASR

SI8660BD-ASR is Low Power Six-Channel Digital Isolator. Data rates up to 150 Mbps are supported, and all devices achieve propagation delays of less than 10 ns.

Specification Of SI8660BD-ASR

Features Of SI8660BD-ASR

High-speed operation: DC to 150 Mbps
No start-up initialization required
Wide Operating Supply Voltage: 2.5–5.5 V
Up to 5000 VRMS isolation
60-year life at rated working voltage
High electromagnetic immunity
Ultra low power (typical)
5 V Operation
- 1.6 mA per channel at 1 Mbps
- 5.5 mA per channel at 100 Mbps
2.5 V Operation
- 1.5 mA per channel at 1 Mbps
- 3.5 mA per channel at 100 Mbps
Schmitt trigger inputs
Selectable fail-safe mode
Default high or low output (ordering option)
Precise timing (typical)
- 10 ns propagation delay
- 1.5 ns pulse width distortion
- 0.5 ns channel-channel skew
- 2 ns propagation delay skew
- 5 ns minimum pulse width
Transient Immunity 50 kV/µs
AEC-Q100 qualification
Wide temperature range: –40 to 125 °C

Applications Of SI8660BD-ASR
Automotive Applications
• On-board chargers
• Battery management systems
• Charging stations
• Traction inverters
• Hybrid Electric Vehicles
• Battery Electric Vehicles
Industrial Applications
• Industrial automation systems
• Medical electronics
• Isolated switch mode supplies
• Isolated ADC, DAC
• Motor control
• Power inverters
• Communication systems
