TPSM84624MOLR Integrated Circuit Chip 6A Power Modules QFM24 Non-Isolated PoL Modules

TPSM84624MOLR Integrated Circuit Chip 6A Power Modules QFM24 Non-Isolated PoL Modules​

Product Description Of TPSM84624MOLR

TPSM84624MOLR power module is an easy-to-use integrated power supply that combines a 6-A DC/DC converter with power MOSFETs, a shielded inductor and passives into a small form-factor QFM package. This power solution allows as few as six external components while maintaining the ability to adjust key parameters to meet specific design requirements.

Specification Of TPSM84624MOLR

Features Of TPSM84624MOLR

Integrated Inductor Power Solution
7.5 mm × 7.5 mm × 5.3 mm QFM Package
– All Pins Accessible From Package Perimeter
Input Voltage Range: 4.5 V to 17 V
Wide-Output Voltage Range: 0.6 V to 10 V
Efficiencies up to 96%
Adjustable Fixed Switching Frequency (200 kHz to 1.6 MHz)
Allows Synchronization to an External Clock
Ultra-Fast Load Step Response (TurboTrans™)
Power-Good Output
Operating Ambient Range: –40°C to +105°C
Operating IC Junction Range: –40°C to +150°C

Applications Of TPSM84624MOLR
Telecom and Wireless Infrastructure
Industrial Automated Test Equipment
Enterprise Switching and Storage Applications
High Density Distributed Power Systems
