Product Description Of TCAN11625DMTRQ1

TCAN11625DMTRQ1 is high-speed controller area network (CAN) system basis chips (SBC) that meet the physical layer requirements of the ISO 11898-2:2016 high-speed CAN specification. The TCAN11625DMTRQ1 supports both classical CAN and CAN FD networks up to 8 megabits per second (Mbps).

TCAN11625DMTRQ1 support a wide input supply range and integrates some form of an LDO output. The TCAN11625DMTRQ1 has a 5-V LDO output (VCCOUT) which supplies the CAN transceiver voltage internally as well as additional current externally.

Specification Of TCAN11625DMTRQ1

Features Of TCAN11625DMTRQ1

Wide input operational voltage range
Integrated LDO for CAN transceiver supply
– 5-V LDO with 100 mA output current capability
Classic CAN and CAN FD up to 8 Mbps
VIO level shifting supports: 1.7 V to 5.5 V
Operating modes
– Normal mode
– Standby mode
– Low-power sleep mode
High-voltage INH output for system power control
Local wake-up support via the WAKE pin
Defined behavior when unpowered
– Bus and IO terminals are high impedance (no load to operating bus or application)
Protection features:
– ±58-V CAN bus fault tolerant
– Load dump support on VSUP
– IEC ESD protection
– Under-voltage and over-voltage protection
– Thermal shutdown protection
– TXD dominant state timeout (TXD DTO)
Extra wide junction temperature support

Applications Of TCAN11625DMTRQ1
Advanced driver assistance system (ADAS)
Body electronics and lighting
Automotive infotainment and cluster
Hybrid, electric and powertrain systems
