Product Overviews Of HD3SS215ZXHR

HD3SS215ZXHR is a high-speed wide common mode passive switch capable of supporting DisplayPort HBR2 and high definition multimedia interface (HDMI) applications requiring 4k2k 60Hz refresh rates.

HD3SS215ZXHR can be configured to support two sources to one sink or one source to two sinks. To support these video standards the HD3SS215ZXHR also switches the display data channel (DDC) and hot plug detect (HPD) signals for HDMI or digital video interface (DVI) applications. It also switches the auxiliary (AUX) and hot plug detect (HPD) signals for DisplayPort applications.

The flexibility the HD3SS215ZXHR provides by supporting both wide common mode and AC or DC coupled links makes it ideal for many applications.

Specification Of HD3SS215ZXHR

Features Of HD3SS215ZXHR

General purpose 2:1/1:2 differential switch
Compatible with displayport electrical standard
Compatible with hdmi electrical standards
2:1 and 1:2 switching supporting data rates up to 6Gbps
Supports HPD switching
Supports AUX and DDC switching
Wide –3-dB differential bandwidth of 7 GHz
Excellent dynamic characteristics (at 3 GHz)
– Crosstalk = –35 dB
– Isolation = –21 dB
– Insertion Loss = –1.6 dB
– Return Loss = –12 dB
– Max Bit-Bit Skew = 5 ps
VDD operating range 3.3 V ±10%
Commercial temperature range: 0°C to 70°C
Output enable (OE) pin disables switch to save power
Power consumption:
– Active < 9 mW typical
– Standby < 30 µW maximum (when OE = L)

Applications Of HD3SS215ZXHR

Desktop and Notebook Applications:
– PCI Express Gen 1, Gen 2 Switching
– DP Switching
– HDMI Switching
– LVDS Switching
Connected peripherals & printers
Home theater And entertainment
TV
Gaming
Pro audio, video And signage
