Product Description Of VIPER318HDTR
VIPER318HDTR device is a high-voltage converter that smartly integrates an 800 V avalanche rugged power MOSFET with PWM current-mode control. The 800 V breakdown allows extended input voltage range to be applied, as well as to reduce the size of the DRAIN snubber circuit. The IC can meet the most stringent energy-saving standards as it has very low consumption and operates in pulse frequency modulation at light load. Overvoltage and undervoltage protections with separate and settable intervention thresholds are available at OVP and UVP pins respectively. UVP can also be used as a disabling input for the entire SMPS, with ultra-low residual input power consumption. Integrated HV startup, sense FET, error amplifier and oscillator with frequency jitter allow a complete application to be designed with a minimum component count. Flyback, buck and buck boost topologies are supported.

Specification Of VIPER318HDTR

Feature Of VIPER318HDTR
800 V avalanche-rugged power MOSFET to cover ultra-wide VAC input range
Embedded HV startup and sense FET
Current mode PWM controller
Drain current limit protection (OCP):
710 mA (VIPER317)
850 mA (VIPER318)
990 mA (VIPER319)
Wide supply voltage range: 4.5 V to 30 V
< 20 mW @ 230 VAC in no-load;
< 430 mW @ 230 VAC, 25 0mW output load
Jittered switching frequency reduces the EMI filter cost:
30 kHz ± 7% (type X)
60 kHz ± 7% (type L)
132 kHz ±7% (type H)
Embedded E/A with 1.2 V reference
Built-in soft-start for improved system reliability
Protections with automatic restart:
overload/short-circuit (OLP)
thermal shutdown
overvoltage
Protections without automatic restart:
pulse-skip protection to avoid flux runaway
undervoltage/disable
max. duty cycle

Application Of VIPER318HDTR
Low power SMPS for home appliances, home automation, industrial, consumers, lighting
Low power adapters
