HMC849ALP4CETR Wireless Communication Module High Isolation SPDT Non-Reflective Switch

HMC849ALP4CETR Wireless Communication Module High Isolation SPDT Non-Reflective Switch

Product Description Of HMC849ALP4CETR
HMC849ALP4CETR is a high isolation non-reflective DC to 6 GHz GaAs pHEMT SPDT switch in a low cost leadless surface mount package. The switch is ideal for cellular/WiMAX/4G Infrastructure applications yielding up to 60 dB isolation, low 0.8 dB insertion loss and +52 dBm input IP3. Power handling is excellent up through the 5 - 6 GHz WiMAX band with the switch offering a P1dB compression point of +31 dBm. On-chip circuitry allows a single positive voltage control of 0/+3V or 0/+5V at very low DC currents. An enable input (EN) set to logic high will put the switch in an "all off" state.

Specification Of HMC849ALP4CETR

Feature Of HMC849ALP4CETR
High Isolation: up to 60 dB
Single Positive Control: 0/+3V to +5V
High Input IP3: +52 dBm
Non-Reflective Design
"All Off" State
16 Lead 4x4mm SMT Package: 16mm2

Applications Of HMC849ALP4CETR
Cellular/4G Infrastructure
WiMAX, WiBro & Fixed Wireless
Automotive Telematics
Mobile Radio
Test Equipment
