TPS7B8150QKVURQ1 Integrated Circuit Chip Low Dropout Regulator 150mA LDO Regulator

TPS7B8150QKVURQ1 Integrated Circuit Chip Low Dropout Regulator 150mA LDO Regulator

Product Description Of TPS7B8150QKVURQ1

TPS7B8150QKVURQ1 is a low-dropout (LDO) linear regulator designed for up to 40V VIN applications. With only a 2.7µA typical quiescent current at light load, the device is an optimal solution for powering microcontrollers and controller area network and local interconnect network (CAN/LIN) transceivers in standby systems.

Specification Of TPS7B8150QKVURQ1

Features Of TPS7B8150QKVURQ1

Device junction temperature range: –40°C to 150°C
3V to 40V wide VIN input voltage range with up to 45V transient
Maximum output current: 150mA
Low quiescent current IQ: – 300nA typical when EN = low (shutdown mode)
– 2.7µA typical at light loads
– 4.5µA maximum at light loads
1.5% output-voltage accuracy over line, load and temperature
Maximum dropout voltage: 540mV at 150mA load current for fixed 5V output version
Stable with low-ESR (0.001Ω to 5Ω) ceramic output-stability capacitor (1µF to 200µF)
Fixed 5V, 3.3V and 2.5V output voltage
Integrated fault protection:
– Thermal shutdown
– Short-circuit and overcurrent protection

Applications Of TPS7B8150QKVURQ1
Automotive head units
Headlights
Battery management systems (BMS)
Inverter and motor controls
