ADL5542ACPZ Wireless Communication Module RF Amplifiers 20dB Gain Block Linear Amplifier

ADL5542ACPZ Wireless Communication Module RF Amplifiers 20dB Gain Block Linear Amplifier​

Product Overviews Of ADL5542ACPZ

ADL5542ACPZ is a broadband 20 dB linear amplifier that operates at frequencies up to 6 GHz. The device can be used in a wide variety of CATV, cellular, and instrumentation equipment.

ADL5542ACPZ provides a gain of 20 dB that is stable over frequency, temperature, power supply, and from device to device. The device is internally matched to 50 Ω with an input return loss of 10 dB or better, up to 6 GHz. Only input/output ac coupling capacitors, power supply decoupling capacitors, and an external inductor are required for operation.

Specification Of ADL5542ACPZ

Features Of ADL5542ACPZ

Fixed gain of 20 dB
Operation up to 6 GHz
Input/output internally matched to 50 Ω
Integrated bias control circuit
Output IP3
46 dBm at 500 MHz
40 dBm at 900 MHz
Output 1 dB compression: 20.6 dB at 900 MHz
Noise figure of 3 dB at 900 MHz
Single 5 V power supply
Small footprint 8-lead LFCSP
Pin compatible with 15 dB gain ADL5541
1 kV ESD (Class 1C)
