LM22674MRE-5.0 Integrated Circuit Chip 42V 500mA Step-Down Voltage Regulator With Precision Enable

LM22674MRE-5.0 Integrated Circuit Chip 42V 500mA Step-Down Voltage Regulator With Precision Enable

Product Description Of LM22674MRE-5.0
LM22674MRE-5.0 switching regulator provides all of the functions necessary to implement an efficient high voltage step-down (buck) regulator using a minimum of external components. This easy to use regulator incorporates a 42 V N-channel MOSFET switch capable of providing up to 500 mA of load current. Excellent line and load regulation along with high efficiency (> 90%) are featured. Voltage mode control offers short minimum on-time, allowing the widest ratio between input and output voltages.

Specification Of LM22674MRE-5.0

Feature Of LM22674MRE-5.0
Wide Input Voltage Range: 4.5 V to 42 V
Internally Compensated Voltage Mode Control
Stable with Low ESR Ceramic Capacitors
200 mΩ N-Channel MOSFET
Output Voltage Options:
-ADJ (Outputs as Low as 1.285 V)
-5.0 (Output Fixed to 5 V)
±1.5% Feedback Reference Accuracy
Switching Frequency of 500 kHz
–40°C to 125°C Operating Junction
Temperature Range
Precision Enable Pin
Integrated Boot-Strap Diode
Integrated Soft-Start
Fully WEBENCH® Enabled
LM22674-Q1 is an Automotive Grade Product
that is AEC-Q100 Grade 1 Qualified
(–40°C to +125°C Operating Junction
Temperature)
SO PowerPAD (Exposed Pad)

Application Of LM22674MRE-5.0
Industrial Control
Telecom and Datacom Systems
Embedded Systems
Conversions from Standard 24 V, 12 V and 5 V Input Rails
