AD8099ARDZ Integrated Circuit Chip High Speed Operational Amplifiers SOIC8 Op Amps IC

AD8099ARDZ Integrated Circuit Chip High Speed Operational Amplifiers SOIC8 Op Amps IC​

Product Overviews Of AD8099ARDZ

AD8099ARDZ is an ultralow noise (0.95nV/√Hz) and distortion (-92dBc @ 10MHz) voltage feedback op amp, the combination of which make it ideal for 16- and 18-bit systems. The AD8099ARDZ features a new, highly linear, low noise input stage that increases the full power bandwidth (FPBW) at low gains with high slew rates.

Specification Of AD8099ARDZ

Features Of AD8099ARDZ

Ultralow Noise: 0.95nV/vHz, 2.6pA/vHz
Ultralow Distortion
2nd Harmonic RL=1kΩ, G=+2
-92dB @ 10MHz
3rd Harmonic RL=1kΩ, G=+2
-105dB @ 10MHz
New pinout
Custom external compensation, gain range
-1, +2 to +10
High Speed
GBWP: 3.8GHz
-3dB bandwidth:
700MHz (G=+2)
550MHz (G=+10)
Slew rate:
475V/µs (G=+2)
1350V/µs (G=+10)
Supply current: 15mA
Offset voltage: 0.5mV max
Wide supply voltage range: 5V to 12V

Other Electronic Components In Stock

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
