Product Description Of UPD720114GA

UPD720114GA is a USB 2.0 hub device that complies with the Universal Serial Bus (USB) Specification Revision 2.0 and works up to 480 Mbps. USB 2.0 compliant transceivers are integrated for upstream and all downstream ports.
UPD720114GA works backward compatible either when any one of the downstream ports is connected to a USB 1.1 compliant device, or when the upstream port is connected to a USB 1.1 compliant host.

Specification Of UPD720114GA

Features Of UPD720114GA

Compliant with Universal Serial Bus Specification Revision 2.0 (Data Rate 1.5/12/480 Mbps)
High-speed or full-speed packet protocol sequencer for Endpoint 0/1
4 (Max.) downstream facing ports
Low power consumption (10 μA when hub in idle status, 149 mA when all parts run in HS mode)
All downstream facing ports can handle high-speed (480 Mbps), full-speed (12Mbps), and low-speed (1.5Mbps) transaction.
Supports split transaction to handle full-speed and low-speed transaction on downstream facing ports when Hub controller is working in high-speed mode.
One Transaction Translator per Hub and supports four non-periodic buffers
Supports self-powered and bus-powered mode
Supports individual or global over-current detection and individual or ganged power control
Supports downstream port status with LED
Supports non-removable devices by I/O pin configuration
Support Energy Star for PC peripheral system
On chip Rpu, Rpd resistors and regulator (for core logic)
Use 30 MHz crystal
3.3 V power supply

UPD720114GA——Pin Configuration (Top View)
