Product Description Of ISO5851QDWRQ1
ISO5851QDWRQ1 is a 5.7-kVRMS, reinforced isolated gate driver for IGBTs and MOSFETs with 2.5-A source and 5-A sink current. The input side operates from a single 3-V to 5.5-V supply. The output side allows for a supply range from minimum 15 V to maximum 30 V. Two complementary CMOS inputs control the output state of the gate driver. The short propagation time of 76 ns assures accurate control of the output stage.

Specification Of ISO5851QDWRQ1

Feature Of ISO5851QDWRQ1
Qualified for Automotive Applications
AEC-Q100 Qualified With the Following Results:
Device Temperature Grade 1: –40°C to +125°C Ambient Operating Temperature Range
Device HBM Classification Level 3A
Device CDM Classification Level C6
100-kV/μs Minimum Common-Mode Transient Immunity (CMTI) at VCM = 1500 V
2.5-A Peak Source and 5-A Peak Sink Currents
Short Propagation Delay: 76 ns (Typ),
110 ns (Max)
2-A Active Miller Clamp
Output Short-Circuit Clamp
Fault Alarm upon Desaturation Detection is Signaled on FLT and Reset Through RST
Input and Output Undervoltage Lockout (UVLO) with Ready (RDY) Pin Indication
Active Output Pull-down and Default Low Outputs with Low Supply or Floating Inputs
3-V to 5.5-V Input Supply Voltage
15-V to 30-V Output Driver Supply Voltage
CMOS Compatible Inputs
Rejects Input Pulses and Noise Transients Shorter Than 20 ns
Isolation Surge Withstand Voltage 12800-VPK
Safety-Related Certifications:
8000-VPK VIOTM and 2121-VPK VIORM Reinforced Isolation per DIN V VDE V 0884-10 (VDE V 0884-10):2006-12
5700-VRMS Isolation for 1 Minute per UL 1577
CSA Component Acceptance Notice 5A, IEC 60950–1 and IEC 60601–1 End Equipment Standards
TUV Certification per EN 61010-1 and EN 60950-1
GB4943.1-2011 CQC Certification
All Certifications Complete

Applications Of ISO5851QDWRQ1
Isolated IGBT and MOSFET Drives in:
– HEV and EV Power Modules
– Industrial Motor Control Drives
– Industrial Power Supplies
– Solar Inverters
– Induction Heating
