TPS40428RHAR Integrated Circuit Chip 2 Phase Synchronous Buck Driverless Controller

TPS40428RHAR Integrated Circuit Chip 2 Phase Synchronous Buck Driverless Controller​

Product Description Of TPS40428RHAR

TPS40428RHAR is a PMBus, synchronous buck, driverless controller. It operates in smart power mode with factory default settings, and it can operate in non-smart power mode after PMBus programing and power reboot.
TPS40428RHAR can be configured for dual-output or 2-phase operation. It is also stackable up to 4 phases to support load current as high as 120 A. Interleaved phase shift for 2-. 3-, or 4-phases reduce the input and output ripples therefore reducing input and output capacitance.

Specification Of TPS40428RHAR

Features Of TPS40428RHAR

Smart Power Mode in Factory Default
Single Supply Operation: 4.5 V to 20 V
VOUT from 0.6 V
Dual or Multi-Phase Synchronous Buck Controller
Individual High-Speed AVS Interface
Fast Transient Response
Stackable up to Four Phases
- 2-, 3-, or 4-Phase Interleaved Phase Shifts
- Accurate Current Sharing
PMBus Interface Capability
- Margining Up/Down with 2-mV Step
- Programmable Fault Limit and Response
- ±0.8% VOUT
- Accuracy Current Monitoring
- ±3°C External Temperature Monitoring In Smart Power Mode
- Programmable UVLO ON/OFF Thresholds
- Programmable Soft-Start Time, Turn-On Delay, and Turn-Off Delay
On-Chip Non-Volatile Memory (NVM) to Store Custom Configurations
0.6-V Reference Voltage with 0.5% Accuracy from –40°C to 125°C
Programmable ƒSW from 200 kHz to 1.5 MHz
Supports Pre-biased Output
Differential Remote Sensing
Synchronization to an Extermal Clock
OC/OV/UV/OT Fault Protection
40-Pin, 6 mm × 6 mm, QFN Package

Applications Of TPS40428RHAR
Wireless Infrastructure
Switcher/Router Networking/Server/Storage
