PL00Y-301-10M10 Connectors High Performance Powerlok™ G2 Connector For EV Electric Power Distribution

PL00Y-301-10M10 Connectors High Performance Powerlok™ G2 Connector For EV Electric Power Distribution

Product Description Of PL00Y-301-10M10
PL00Y-301-10M10 Powerlok™ G2 Connector is a high performance, compact, aluminum alloy interconnect solution utilizing RADSOK contact technology for EV and Hybrid transportation applications. G2 provides electrical ratings up to 1000VDC and 450A (@ 50°C Ambient) with IP67/9K sealing, 360° shielding, multiple keying options, straight and right angle configurations, and up to 3 positions. G2 is available as field assembled connectors which accommodate shielding cable sizes from 50mm² to 120mm².

Specification Of PL00Y-301-10M10

Features Of PL00Y-301-10M10
Voltage Rating: 1000VDC
DC Current Rating: up to 450A at 50°C Ambient
Insulation Resistance: 500MΩ
IP rating: IP67&IP6K9K(mated), IP2X(unmated)
Salt Spray: 480H (ISO 9227)
Mating Cycle: 100Min
Temperature range: -40 / +125 °C
UL 94 V-0 compliance (plastic components)
Lever lock with CPA
Modular design, Common Internal Components
Vibration class : LV214 Level 2
1POS, 2POS, 3POS Positions Available
90D(Right angle) and 180D(Straight) Plug Orientations
RADSOK Contact Technology
High Voltage Interlock
360° Shielding, Low Shielding Resistance
RoHS/REACH Compliant

Applications Of PL00Y-301-10M10
POWERLOK G2 series connectors are engineered for a diverse set of applications including electric power distribution for automotive, truck, bus, agricultural, construction, and off-road vehicles.
