IR35201MTRPBF Integrated Circuit Chip Dual Output Digital Multi-Phase Controller
IR35201MTRPBF Integrated Circuit Chip Dual Output Digital Multi-Phase Controller
Description
Part Number:
IR35201MTRPBF
Output Voltage::
2.9 V
Output Current::
100 UA
Number Of Outputs::
2 Output
Input Voltage - Min::
2.9 V
Input Voltage - Max::
3.63 V
IR35201MTRPBF Integrated Circuit Chip Dual Output Digital Multi-Phase Controller
Product Description Of IR35201MTRPBF
IR35201MTRPBF is a dual-loop digital multi-phase buck controller designed for CPU voltage regulation, and is fully compliant with Intel , VR12 Rev 1.7, VR12.5 Rev 1.5, IMVP82 Rev 1.2, and AMD SVI2 REV 1.06 specifications.
Specification Of IR35201MTRPBF
2.9 V
100 uA
2 Output
2.9 V
3.63 V
194 kHz to 2 MHz
- 40 C
+ 85 C
Input Voltage:
2.9 V to 3.63 V
Moisture Sensitive:
Yes
Operating Supply Current:
48 mA
Product Type:
Switching Voltage Regulators
Shutdown:
Shutdown
Unit Weight:
610.691 mg
Features Of IR35201MTRPBF
Ultra Low Quiescent Power Dual output 8 phase (8+0/7+1/ 6+2) PWM Controller
VR12 Rev 1.7, VR12.5 Rev 1.5, IMVP8 Rev 1.2, AMD SVI2, and Memory VR modes
Switching frequency from 194KHz to 2MHz per phase in 56 steps
IR Efficiency Shaping Features including Dynamic Phase Control and Automatic Power State Switching
Programmable 1-phase or 2-phase operation for Light Loads and Active Diode Emulation for very Light Loads
IR Adaptive Transient Algorithm (ATA) on both loops minimizes output bulk capacitors and system cost
Auto-Phase Detection with PID Coefficient autoscaling
Fault Protection: OVP, UVP, OCP, OTP, CAT_FLT
I2C/SMBus/PMBus system interface for reporting of Temperature, Voltage, Current & Power telemetry for both loops
Multiple Time Programming (MTP) with integrated charge pump for easy non-volatile programming
Compatible with 3.3V tri-state drivers
+3.3V supply voltage; -40oC to 85oC ambient operation; -40℃ to 125℃ junction
Pb-Free, RoHS, 7x7mm 56-pin, 0.4mm pitch QFN
Applications Of IR35201MTRPBF
VR12, VR12.5 and IMVP8 (overclocking only), AMD SVI2 based systems
Servers and High End Desktop CPU VRs
High Performance Graphics Processors, Memory VR
