ADUM1401CRWZ Integrated Circuit Chip 2500Vrms Quad Channel Digital Isolator SOIC16

ADUM1401CRWZ Integrated Circuit Chip 2500Vrms Quad Channel Digital Isolator SOIC16​

Product Description Of ADUM1401CRWZ

ADUM1401CRWZ is a quad-channel digital isolator with 3/1 channel directionality. Combining high speed CMOS and monolithic air core transformer technology, these isolation components provide outstanding performance characteristics superior to alternatives, such as optocoupler devices.

ADUM1401CRWZ isolators provide four independent isolation channels in a variety of channel configurations and data rates. It operate with the supply voltage on either side ranging from 2.7 V to 5.5 V, providing compatibility with lower voltage systems as well as enabling a voltage translation functionality across the isolation barrier.

Specification Of ADUM1401CRWZ

Features Of ADUM1401CRWZ

Qualified for automotive applications
Low power operation
Bidirectional communication
3 V/5 V level translation
High temperature operation: 125°C
High data rate: dc to 90 Mbps (NRZ)
Precise timing characteristics
High common-mode transient immunity: >25 kV/μs

Applications Of ADUM1401CRWZ

General-purpose multichannel isolation
SPI interface/data converter isolation
RS-232/RS-422/RS-485 transceivers
Industrial field bus isolation
Automotive systems
