TLD1120EL Integrated Circuit Chip 1 Channel High-Side Driver With Integrated Output Stages

TLD1120EL Integrated Circuit Chip 1 Channel High-Side Driver With Integrated Output Stages

Product Description Of TLD1120EL
TLD1120EL is designed to control LEDs with a current up to 360 mA. In typical automotive applications the device is capable to drive i.e. 3 red LEDs with a current up to 180 mA, which is limited by thermal cooling aspects. The output current is controlled practically independent of load and supply voltage changes.

Specification Of TLD1120EL

Features Of TLD1120EL
1 Channel device with integrated output stage (current source), optimized to drive LEDs
Output current up to 360mA
Low current consumption in sleep mode
PWM-operation supported via VS- and EN-pin
Output current adjustable via external low power resistor and possibility to connect PTC resistor for LED protection during over temperature conditions
Reverse polarity protection
Overload protection
Undervoltage detection
Wide temperature range: -40 °C < T j < 150 °C
PG-SSOP14 package with exposed heatslug
Green Product (RoHS compliant)
AEC Qualified

Applications Of TLD1120EL
Designed for exterior LED lighting applications such as tail/brake light, turn indicator, position light, side marker
The device is also well suited for interior LED lighting applications such as ambient lighting, interior illumination and dash board lighting
