MAX6816EUS Integrated Circuit Chip 15kV ESD-Protected Single CMOS Switch Debouncers

MAX6816EUS Integrated Circuit Chip 15kV ESD-Protected Single CMOS Switch Debouncers

Product Description Of MAX6816EUS
MAX6816EUS is single switch debouncers that provide clean interfacing of mechanical switches to digital systems. They accept one or more bouncing inputs from a mechanical switch and produce a clean digital output after a short, preset qualification delay. Both the switch opening bounce and the switch closing bounce are removed. Robust switch inputs handle ±25V levels and are ±15kV ESD-protected for use in harsh industrial environments. They feature single-supply operation from +2.7V to +5.5V. Undervoltage lockout circuitry ensures the output is in the correct state upon power-up.

Specification Of MAX6816EUS

Features Of MAX6816EUS
Switch Debouncer Integration Simplifies System Interface to Mechanical Switches
Single-Supply Operation from +2.7V to +5.5V
No External Components Required
6µA Supply Current
Built-In Protection Circuitry Improves System Reliability
Inputs Can Exceed Power Supplies up to ±25V
ESD Protection for Input Pins
±15kV—Human Body Model
±8kV—IEC 1000-4-2, Contact Discharge
±15kV—IEC 1000-4-2, Air-Gap Discharge

Applications Of MAX6816EUS
µP Switch Interfacing
Industrial Instruments
Membrane Keypads
PC-Based Instruments
Portable Instrumentation
