LTC2052HVIS Integrated Circuit Chip Operational Amplifiers SOIC14 Quad Zero Drift Op Amps

LTC2052HVIS Integrated Circuit Chip Operational Amplifiers SOIC14 Quad Zero Drift Op Amps​

Product Description Of LTC2052HVIS

LTC2052HVIS is quad zero-drift operational amplifiers, it operate from a single 2.7V supply and support ±5V applications. The current consumption is 750µA per op amp.

LTC2052HVIS despite their miniature size, feature uncompromising DC performance. The typical input offset voltage and offset drift are 0.5µV and 10nV/°C. The almost zero DC offset and drift are supported with a power supply rejection ratio (PSRR) and common mode rejection ratio (CMRR) of more than 130dB.

Specification Of LTC2052HVIS

Features Of LTC2052HVIS

Maximum Offset Voltage of 3µV
Maximum Offset Voltage Drift of 30nV/°C
Small Footprint, Low Profile MS8/GN16 Packages
Single Supply Operation: 2.7V to ±5.5V
Noise: 1.5µVP-P (0.01Hz to 10Hz Typ)
Voltage Gain: 140dB (Typ)
PSRR: 130dB (Typ)
CMRR: 130dB (Typ)
Supply Current: 0.75mA (Typ) per Amplifier
Extended Common Mode Input Range
Output Swings Rail-to-Rail
Operating Temperature Range –40°C to 125°C

Applications Of LTC2052HVIS

Thermocouple Amplifiers
Electronic Scales
Medical Instrumentation
Strain Gauge Amplifiers
High Resolution Data Acquisition
DC Accurate RC Active Filters
Low Side Current Sense
