LM5022MM Integrated Circuit Chip 60V Low-Side Controller For Boost And SEPIC

LM5022MM Integrated Circuit Chip 60V Low-Side Controller For Boost And SEPIC

Product Description Of LM5022MM
LM5022MM device is a high-voltage, low-side, N-channel MOSFET controller ideal for use in boost and SEPIC regulators. It contains all of the features required to implement single-ended primary topologies. Output voltage regulation is based on current-mode control, which eases the design of loop compensation while providing inherent input voltage feedforward. The LM5022MM includes a start-up regulator that operates over a wide input range of 6 V to 60 V. The PWM controller is designed for high-speed capability including an oscillator frequency range up to 2.2 MHz and total propagation delays less than 100 ns. Additional features include an error amplifier, precision reference, line undervoltage lockout, cycle-by-cycle current limit, slope compensation, soft start, external synchronization capability, and thermal shutdown. The LM5022MM is available in the 10-pin VSSOP package.

Specification Of LM5022MM

Features Of LM5022MM
Internal 60-V start-up regulator
1-A Peak MOSFET gate driver
VIN Range: 6 V to 60 V (operates down to 3 V after start-up)
Duty cycle limit of 90%
Programmable UVLO with hysteresis
Cycle-by-cycle current limit
External synchronizable (AC-coupled)
Single resistor oscillator frequency set
Slope compensation
Adjustable soft start
10-Pin VSSOP package

Applications Of LM5022MM
Boost converters
SEPIC converters
