TPS54331DR Integrated Circuit Chip 3A 570kHz Step Down DC-DC Converter With Eco-Mode
The TPS54331DR device is a 28-V, 3-A non-synchronous buck converter that integrates a low RDS(on) high-side MOSFET. To increase efficiency at light loads, a pulse skipping Eco-mode feature is automatically activated. Furthermore, the 1-µA shutdown supply-current allows the device to be used in battery-powered applications.
Technical Specifications
| Parameter | Value |
|---|
| Topology | Buck |
| Output Voltage | Adjustable |
| Output Current | 3 A |
| Number of Outputs | 1 Output |
| Input Voltage - Min | 3.5 V |
| Input Voltage - Max | 28 V |
| Quiescent Current | 1 µA |
| Switching Frequency | 570 kHz |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +150 °C |
| Input Voltage | 3.5 V to 28 V |
| Operating Supply Current | 110 µA |
| Unit Weight | 72.600 mg |
Key Features
3.5 to 28-V input voltage range
Adjustable output voltage down to 0.8 V
Integrated 80-mΩ high-side MOSFET supports up to 3-A continuous output current
High efficiency at light loads with pulse skipping Eco-mode
Fixed 570-kHz switching frequency
Typical 1-µA shutdown quiescent current
Adjustable slow-start limits inrush currents
Programmable UVLO threshold
Overvoltage transient protection
Cycle-by-cycle current limit, frequency foldback, and thermal shutdown protection
Available in easy-to-use SOIC8 package or thermally-enhanced SOIC8 PowerPAD™ integrated circuit package
Create custom designs using TPS54331 with WEBENCH® Power Designer
Typical Applications
- Consumer applications such as set-top boxes, CPE equipment, LCD displays, peripherals, and battery chargers
- Industrial and car-audio power supplies
- 5-V, 12-V, and 24-V distributed power systems
