DS125MB203SQ Integrated Circuit Chip 12.5Gbps Dual Port Mux And Fanout Buffer With Equalization And De-Emphasis

DS125MB203SQ Integrated Circuit Chip 12.5Gbps Dual Port Mux And Fanout Buffer With Equalization And De-Emphasis

Product Description Of DS125MB203SQ
DS125MB203SQ device is a dual port 2:1 multiplexer and 1:2 switch or fan-out buffer with signal conditioning suitable for 10GE, 10G-KR (802.3ap), Fibre Channel, PCIe, Infiniband, SATA3/SAS2 and other high-speed bus applications with data rates up to 12.5 Gbps. The continuous time linear equalizer (CTLE) of the receiver provides necessary boost to compensate up to 30-inch FR-4 or 8-m cable (AWG-24) at 12.5 Gbps. This on-chip feature eliminates the need for external signal conditioners. The transmitter features a programmable amplitude voltage levels to be selectable from 600 mVp-p to 1300 mVp-p and de-emphasis of up to 12 dB.

Specification Of DS125MB203SQ

Features Of DS125MB203SQ
12.5-Gbps Dual Lane 2:1 Mux, 1:2 Switch or Fanout
Low 390-mW Total Power (Typical)
Advanced Signal Conditioning Features:
Receive Equalization up to 30 dB at 6.25 GHz
Transmit De-Emphasis up to –12 dB
Transmit Output-Voltage Control: 600 mV to 1300 mV
Programmable Through Pin Selection, EEPROM or SMBus Interface
Selectable 2.5-V or 3.3-V Supply Voltage
–40°C to +85°C Operating Temperature Range

Applications Of DS125MB203SQ
10GE, 10G-KR
PCIe Gen-1/2/3
SAS2/SATA3 (Up to 6 Gbps)
XAUI, RXAUI
