BSC059N04LS6 Integrated Circuit Chip 40V OptiMOS 6 Power MOSFET Transistors

Large Image : BSC059N04LS6 Integrated Circuit Chip 40V OptiMOS 6 Power MOSFET Transistors

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	BSC059N04LS6

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	PG-TDSON-8
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

BSC059N04LS6 Integrated Circuit Chip 40V OptiMOS 6 Power MOSFET Transistors

Description

Part Number:	BSC059N04LS6	VDS Max:	40 V
IDpuls Max:	236 A	Ptot Max:	38 W
Package:	SuperSO8 5x6	Operating Temperature:	-55 °C To 175 °C
Highlight:	BSC059N04LS6 , BSC059N04LS6 Integrated Circuit Chip , 40V OptiMOS 6 Power MOSFET Transistors

BSC059N04LS6 Integrated Circuit Chip 40V OptiMOS 6 Power MOSFET Transistors

Product Description Of BSC059N04LS6

BSC059N04LS6 is 40V, OptiMOS™ 6 power MOSFETs Transistors combining best-in-class RDS(on) with superior switching performance.

Specification Of BSC059N04LS6

Series	OptiMOS™
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	40 V
Current - Continuous Drain (Id) @ 25°C	17A (Ta), 49A (Tc), 59A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	5.9mOhm @ 50A, 10V
Vgs(th) (Max) @ Id	2.3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	9.4 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	830 pF @ 20 V
Power Dissipation (Max)	3W (Ta), 38W (Tc)
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	PG-TDSON-8-6
Package / Case	8-PowerTDFN

Features Of BSC059N04LS6

Compared to alternative products:
RDS(on) reduced by 30%
Improved FOM Qg x RDS(on) by 29%
Improved FOM Qgd x RDS(on) by 46%
Optimized for synchronous rectification
Suited for ORing circuits
RoHS compliant
halogen free
MSL1 rated

Applications Of BSC059N04LS6
