ESP-12F Wireless Communication Module High-Performance 2.4 GHz 802.11 b/g/n WiFi Module

ESP-12F Wireless Communication Module High-Performance 2.4 GHz 802.11 b/g/n WiFi Module

Product Description Of ESP-12F
The ESP-12F is a WiFi module featuring the ESP8266 core processor, which integrates the industry-leading Tensilica L106 ultra-low-power 32-bit microcontroller (MCU) in a compact package, complete with a 16-bit reduced mode. with support for clock speeds of 80 MHz and 160 MHz, RTOS compatibility, and integrated Wi-Fi MAC/BB/RF/PA/LNA functionality, along with an onboard antenna.

The module supports the standard IEEE 802.11 b/g/n protocol and a complete TCP/IP protocol stack. Users can use this module to add networking functionality to existing devices or build independent network controllers.

Specification Of ESP-12F

Features Of ESP-12F
802.11 b/g/n
Built-in Tensilica L106 ultra-low-power 32-bit microcontroller, supporting clock speeds of 80 MHz and 160 MHz, and supporting RTOS
Built-in 10-bit high-precision ADC
Built-in TCP/IP protocol stack
Built-in TR switch, balun, LNA, power amplifier, and matching network
Built-in PLL, regulator, and power management components, with an output power of +20 dBm in 802.11b mode
Aggregation of A-MPDU and A-MSDU, with a protection interval of 0.4 seconds
WiFi at 2.4 GHz, supporting WPA/WPA2 security modes
Supports AT process upgrades and cloud-based OTA upgrades
Supports STA/AP/STA+AP operating modes
Supports Smart Config functionality (including Android and iOS devices)
HSPI, UART, I2C, I2S, IR Remote Control, PWM, GPIO
Deep sleep mode current consumption: 10 uA, shutdown current less than 5 uA
Wake up, connect, and transmit data packets within 2 ms
Standby mode power consumption less than 1.0 mW (DTIM3)
Operating temperature range: -40°C to 125°C

Other Supply Product Types

FAQ

Q: Are your products original?

A: Yes, all products are original, new original import is our purpose.

Q:Which Certificates do you have?

A:We are ISO 9001:2015 Certified Company and member of ERAI.

Q:Can you support small quantity order or sample?Is the sample free?

A:Yes,we support sample order and small order.Sample cost is different according to your order or project.

Q:How to ship my order? Is it safe?

A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.

Q:What about the lead time?

A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
